After completing this course, you should be able to perform basic ControlLogix® and Studio 5000 Logix Designer® tasks, such as:

• Creating and configuring a project
• Communicating with a controller

The course will assist you in developing and building a solid
foundation with a fundamental knowledge of ControlLogix and
other Logix5000™ systems.

You will be introduced to basic Logix5000 concepts and terminology, and you will be exposed to Logix5000 system hardware, including hands-on experience with the ControlLogix platform.

This course is designed to provide knowledge and skills required to install, maintain and troubleshoot machine controls.

At the completion of this course, you will be able to:

- Define the safety considerations that must be observed when installing, checking or locking out electrical equipment
- Define uses and functions of input and output devices, relays, and motors
- Demonstrate the reading of schematic diagrams and logic
- Define an open and short condition and perform voltage and current
measurements
- Demonstrate the proper use of the following test equipment in lab to measure voltage, current, resistance and continuity: VOM, DVM, Multi-meters, continuity tester and amp probe
- Approximate secondary voltage, secondary current and primary current of a transformer when given its turns ratio, primary voltage and secondary load
- Identify the proper wiring configurations of a control transformer’s primary current for 240V and 480V operation
- Approximate a transformer’s maximum primary current for 480V operation, using the nameplate information
